Industrial Electrical Fiberglass Armor Tape KC88

Designed for insulation of copper and aluminum busbars- for electrical substations and switchgear cabinets. Can be used for exterior installations

Shrink ratio: 2.5:1

Operating voltage: 35 kV

Material: polyolefin, halogen-free (HF)

Analogs: BPTM (Raychem); BBI (3M)

Resistant to the phenomenon of tracking and UV radiation

High dielectric strength

Color: brick red

Shorten the distance between phase busbars and significantly reducing the dimensions of the device

Protect electrical busbars against chemical corrosion

Protect equipment from short circuits in case of contact of electrical devices with animals and birds

KC9001 Flexible fireproof and explosion-proof blanket is suitable for the outer wrapping of the cable straight joint. It adopts multi-layer protective structure to cover the cable straight joint. The outer layer is made of ablation-resistant fireproof cloth with built-in flexible nano thermal insulation sheet and high strength aramid fiber cloth. When the fire broke out, the built-in can flexible nano can get insulation sheet is 3 ~ 4 times of that of the traditional performance, at the same time the highest heat resistance is above 1200 ℃, and it has excellent flame retardant and heat insulation effect, and the built-in high strength aramid fiber cloth can avoid the middle joint breakdown exploded the harm of adjacent cables, avoid the secondary damage caused by the fire. KC9001 light flexible fireproof blanket is easy to install, and it can be easily installed outside the cable intermediate connector after construction by means of pre-installed fire-resistant tie belt and D-type ring clasp without other tools.

The shear bolt connectors are intended for stranded and solid aluminum and copper cable, low voltage and medium voltage up to 36 kV.

They comprise cable areas 10-400 mm² even bigger for sector cable. There is also a screw sleeve for branches up to a total of 100 mm². The joint with the conductor is achieved by the screws in the connector or terminal being tightened to a predetermined torque.

Cotran heat shrink terminations and joints are composed of a series of pre-expanded adhesive lined heat shrink tubes and necessary accessories. Heat shrink and provide excellent waterproof seal and electrical insulation. The terminations and joints are designed to be suitable for SWA/UA, XLPE/PVC/PILC, S/C, multi-core cable rated to 0.6/1kV.

Applications：

suitable for American 200A electrical system, installed on the 200A interface of the high voltage outlet of American box substation, ring main cabinet, cable branch box, buried transformer and other electrical equipment to provide overvoltage protection for electrical equipment.

The product interface complies with the 200A casing design in the standard IEEE386.

COTRAN Cold shrink rubber end caps are usually used for environmentally seal and mechanically protect exposed cable ends using no tools, mastics or tapes. Cold shrink EPDM end caps are close-ended, tubular rubber tube that are factory expanded and loaded onto a removable core. When positioned over the end of a cable, or other cylindrical object, the core is removed to provide a reliable seal that protects your cable ends from environmental damage, like moisture, contamination and corrosion etc.

◆Excellent surface flatness

◆Large thermal transfer area

◆Flexibleflow channel design

◆Easyprocessing and shaping

◆Goodthermaldissipation effect

◆Low leakage risk and high safety

◆Good pressure resist and strength

◆High production efficiency and yield

◆High production efficiency

◆Large thermal contact area

◆Uniform and stable welding

◆Rapid thermal cooling speed

◆Thin thickness to save space

◆Easy processing and shaping

◆Good thermal exchange effect

◆Low leak risk and high security
