Screen Separable Cable Connector (6~36kV)

Applications：

The Separable Connector establishes the connection between any polymeric insulated cable onto transformers, switchgears, motors or other equipment.

Inquiry now

product introduction

Features：

Material performance: LSR (Liquid Silicone Rubber) is a material with excellent characteristics, such as ageing resistance, weathering resistance, hydrophobicity, Electrical performance stability, tensile strength, etc.
Structure: Stress cone is designed with geometric structure which keeps the steady active pressure to cable.
Electrical performance: The integrated LSR geometric stress cone provides high performances for Screened Connector, such as rugged structure, well-elasticity and reliable long-term operation.

Technical properties

Standard	IEC 60502
Voltage classes	6/10(12)kV	8.7/15(17.5)kV	12/20(24)kV	18/30(36)kV
Partial discharge test at ambient temperature	10kV, <10pC	15kV, <10pC	20kV, <10pC	30kV, <10pC
AC withstand voltage test	27kV 5min	39kV 5min	54kV 5min	81kV 5min
Impulse voltage withstand	±75kV each polarity 10 times	±95kV each polarity 10 times	±125kV each polarity 10 times	±170kV each polarity 10 times

Selection table:

6/10(12)kV
Screen cable Connector	Screen Rear cable Connector	Cable Insulation OD(mm)	Cable Conductor Cross-section(mm²)
AQ-12-630A-A	AH-12-630A-A	16.5mm-20.9mm	70mm²--95mm²
AQ-12-630A-B	AH-12-630A-B	20.3mm-24.3mm	120-mm²--185mm²
AQ-12-630A-C	AH-12-630A-C	24.7mm-29.5mm	240mm²--300mm²
AQ-12-630A-D	AH-12-630A-D	29.5mm-36.3mm	400mm²--500mm²
AQ-12-630A-E	AH-12-630A-E	34.5mm-41.5mm	630mm²
8.7/15(17.5)kV
Screen cable Connector	Screen Rear cable Connector	Cable Insulation OD(mm)	Cable Conductor Cross-section(mm²)
AQ-17.5-630A-A	AH-17.5-630A-A	16.5mm-20.9mm	25mm²--50mm²
AQ-17.5-630A-B	AH-17.5-630A-B	20.3mm-24.3mm	70mm²--120mm²
AQ-17.5-630A-C	AH-17.5-630A-C	24.7mm-29.5mm	150mm²--185mm²
AQ-17.5-630A-D	AH-17.5-630A-D	29.5mm-36.3mm	240mm²--400mm²
AQ-17.5-630A-E	AH-17.5-630A-E	34.5mm-41.5mm	500mm²--630mm²
12/20(24)kV
Screen cable Connector	Screen Rear cable Connector	Cable Insulation OD(mm)	Cable Conductor Cross-section(mm²)
AQ-24-630A-A	AH-24-630A-A	16.5mm-20.9mm	35mm²--50mm²
AQ-24-630A-B	AH-24-630A-B	20.3mm-24.3mm	70mm²--95mm²
AQ-24-630A-C	AH-24-630A-C	24.7mm-29.5mm	120mm²--185mm²
AQ-24-630A-D	AH-24-630A-D	29.5mm-36.3mm	240mm²--300mm²
AQ-24-630A-E	AH-24-630A-E	34.5mm-41.5mm	400mm²-500mm²
18/30(36)kV
Screen cable Connector	Screen Rear cable Connector	Cable Insulation OD(mm)	Cable Conductor Cross-section(mm²)
AQ-36-630A-A	AH-36-630A-A	25.2mm—30.2mm	50mm²--95mm²
AQ-36-630A-B	AH-36-630A-B	30.2mm—35.9mm	120mm²--185mm²
AQ-36-630A-C	AH-36-630A-C	35.9mm—41.2mm	240mm²--300mm²
AQ-36-630A-D	AH-36-630A-D	41.2mm--44.5mm	400mm²--500mm²

*NOTE:

1. Cable insulation outer diameter is one of the prerequisite for cable accessories selection.

2. For three-core cable, AQ/AH should be separately ordered.

3. The connector suit for bushings according to EN 50181, connection type C.
